SAMLEX AMERICA Solar Charging Kit with SCC-30AB 30A Charge Controller
Customize
The SAMLEX AMERICA Solar Charging Kit bundles a high-efficiency crystalline solar panel with the SCC-30AB 30A charge controller and all necessary mounting hardware and wiring to support 12V and 24V battery systems. The included SCC-30AB controller features micro-processor control, 30 Amp charging capacity, battery equalization, a digital LCD that indicates voltage, current and battery AH, 4-stage charging, and multiple charge settings for different battery types; an optional remote temperature sensor is supported. Panels use anodized aluminum frames and tempered/reinforced glass with a low-profile design and include top-quality cables and mounting brackets; wiring is protected for outdoor use. These kits are suited for recreational vehicles, off-grid and mobile solar systems, remote equipment and monitoring applications, and other remote power or battery charging needs.
- Dimensions: 26 x 14.74 x 1.38 inches (length x width x height)
- Mounting: Aluminum mounting brackets and hardware for secure installation
- Connector Type: USB connector type for versatile use
- Design: Low profile panel design for streamlined installation
- Cell Type: High efficiency crystalline solar cells for optimal performance
- Construction: All weather anodized aluminum and tempered glass construction
- Included Components: Solar panel, charge controller, connecting wires, brackets, and hardware
- High Efficiency: 150 watt solar panel for efficient energy conversion
Specifications:
| Materials & Construction | |
| Outer Material | Anodized Aluminum |
| Product Details | |
| Manufacturer Part No | SRV-150-30A |
| Maximum Power | 150 Watts |
| Model | SRV-150-30A |
| Model Number | SRV-150-30A |
| Sizing & Dimensions | |
| Height | 1.38 inches |
| Length | 57.91 inches |
| Product Dimensions | 57.91 x 26.22 x 1.38 inches |
| Size | 57.91 x 26.22 x 1.38 inches |
| Weight | 40 pounds |
| Width | 26.22 inches |
| Technical Specifications | |
| Maximum Power | 150 Watts |
