Ancor 104050 Marine Grade Electrical Primary Tinned Copper Boat Wiring (14-Gauge, Black, 500-Feet)
Customize
Black 14 AWG Tinned Copper Wire - 500' Ancor Marine Grade wire products are the longest lasting and most rugged available, exceeding UL 1426, ABYC and US Coast Guard Charter boat (CFR Title 46) standards. They are constructed with premium vinyl insulation that is rated at 600 volts, 105°C dry and 75°C wet, stays flexible even in extreme cold (-40°) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation. Highest quality ultra flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing. Manufactured from tinned copper stranding for maximum protection against corrosion and electrolysis. Ultra-flexible (Type 3) stranding helps prevent fatigue due to vibration and flexing. Ancor's proprietary premium vinyl insulation stays flexible even in extreme cold (-40° F/ -40° C) and resists salt water, battery acid, oil, gasoline, and ultraviolet radiation. The wire's exclusive insulation is rated at 600 volts, 221° F / 105° C dry and 167° F / 75° C wet, and is engineered to withstand heat and abrasions. Exceeds all UL 1426, US Coast Guard Charter boat (CFR Title 46), and ABYC standards. 500 Feet of Black 14 AWG marine grade wire. WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
- 500 Feet of Black 14 AWG marine grade wire
- Manufactured from individual copper strands and tinned to perform in the harshest marine environments
- Ultra-flexible Type 3 stranding resists fatigue from vibration and provides added corrosion protection
- Exceeds all UL 1426, US Coast Guard Charter boat (CFR title 46) and ABYC standards
- They are constructed with premium vinyl insulation that is rated at 600 volts, 105 deg C dry and 75 deg C wet, stays flexible even in extreme cold (-40 deg F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation
Specifications:
| Materials & Construction | |
| Color | Black |
| Material | Tinned Copper |
| Outer Material | Tinned Copper |
| Product Details | |
| Gauge | 14 Awg |
| Included Components | wire |
| No. of wires | 1 |
| Number of Cable Strands | Multi Strand |
| Size | 500 Feet |
| Style | 14 Awg |
| Voltage | 600 Volts |
| Sizing & Dimensions | |
| Height | 5 inches |
| Length | 7 inches |
| Product Dimensions | 7 x 7 x 5 inches |
| Size | 500 Feet |
| Weight | 2.9 pounds |
| Width | 7 inches |
| Technical Specifications | |
| Warranty | 1 year limited |
