Blue Sea Systems 5114 Fuse A3T/Class T 150A Boating Electrical Equipment
Blue Sea Systems 5114 Class T 150A cartridge fuse for marine and DC electrical systems. UL-listed, extremely fast short‑circuit response with 20,000 AIC. Plastic construction; through-hole mounting.
$82.99 $82.99
Customize
Available Quantity
4 Product Details
Blue Sea Systems 5114 Class T 150A Fuse. Extremely fast short-circuit response with 20,000 Ampere Interrupt Capacity (AIC). UL listed to standard 248-15 and DC tested to UL standard 198L. Rated 150A and suitable for marine/DC electrical applications; mounting type: through-hole. Constructed of plastic. Package and product dimensions provided; packaged as a single fuse unit. WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
- Amperage: 150a, max voltage: 160V DC
- Interrupt capacity: 20, 000a at 160V DC
- Extremely fast short-circuit response
Specifications
Materials & Construction
- Outer Material:Plastic
Product Details
- AC Adapter Current:150 Amps
- Amperage:150a
- Color:No Color
- Fuse Type:Class T
- Global Trade Identification Number:00632085051143
- Included Components:Fuse
- Material:Plastic
- Model Name:Fuse A3T/Class T 150A
- Mounting Type:Through-Hole Mount
- Number of Items:1
- Specification Met:UL
- Type:Fuses
- Unit Count:1.0 Count
- UPC:632085051143
- Voltage:125 Volts
Sizing & Dimensions
- Height:5.6 inches
- Length:1.7 inches
- Product Dimensions:1.7 x 3.5 x 5.6 inches
- Size:One Size
- Weight:2.47 ounces
- Width:3.5 inches
Technical Specifications
- Max Voltage:160V DC
