Jabsco P601J-215S-3A, ParMax HD6-12V 6GPM 40PSI Heavy Duty Freshwater Delivery Pump, Black
Customize
Par-Max HD6 Heavy Duty Water Pressure Pump - 12V - 6 GPM - 40 PSI HD (Heavy Duty) models include a wider diameter motor with a powder coated shell, cast aluminum endbells and lower housing to improve pressure capability and life. Available in configurations up to 6 GPM (23 LPM) and 60 PSI (4.1 BAR), these pumps deliver exceptional performance. Standard models provide good performance in an economical footprint. These configurations are available in 1-3 GPM, perfect for vessels with 1-3 outlets. A plastic housing protects the motors on these units from corrosion. Features: Co-molded diaphragm technology for long life and durability HD models feature heavy duty, motors and cast aluminum lower housings which allow for longlife, even at high pressures Efficient and quiet operation Integrated, sealed pressure switch for on-demand operation Self-priming allows for installation versatility Can run dry without damage Quick connect ports for ease of installation, servicing, and maintenance Vibration dampening mounting feet Equipped with integrated bypass module to reduce cycling and provide smoother flow. Great Product
- Great Product
Specifications:
| Materials & Construction | |
| Color | Black |
| Material | Aluminum, Polypropylene (PP) |
| Outer Material | Aluminum, Polypropylene (PP) |
| Product Details | |
| Model Number | P601J-215S-3A |
| Power Source | Corded Electric |
| Style | Diaphragm |
| UPC | 671880841979 |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 6 inches |
| Length | 15 inches |
| Product Dimensions | 15"L x 6"W x 6"H |
| Size | No Size |
| Weight | 1 pounds |
| Width | 6 inches |
| Technical Specifications | |
| Dry self-priming capability | 7ft min (2.13m/min) |
| Gallons Per Minute | 6 Gpm |
| Max Psi | 40 |
| Maximum Flow Rate | 6 Gallons Per Minute |
| Voltage | 12 Volts (DC) |
