Egis RT Fuse Block 6 Position w/LED Indication
Customize
RT Fuse Block 6 Position with LED Indication. This 6-position fuse block has a modular design that can produce seven unique configurations from Egis 8028 & 8030 to reduce part numbers for build requirements. LED blown-fuse indication speeds fault correction and remote diagnosis. Harsh-environment design with stainless steel self-locking hardware and optional weather-proof labels. Features bullet-proof construction with high-temperature materials, supports ATO/ATC/ATF fuses 1–40 Amps, accepts #10 AWG max output wire, supports SAE circuit protection standards, and provides two spare fuse locations per 6 circuits. Applications include vehicle branch circuit protection and improved diagnostics for blown fuses. Specifications: Maximum Current (Entire Block): 100 Amps; Maximum Current (Per Circuit): 30 Amps; Max Output Wire Size: #10 AWG; Voltage Range VDC: 0-36; Number of Fuse Positions: 6; Compatible Fuse Types: ATO / ATC / ATF.
- Great Product
Specifications:
| Materials & Construction | |
| Color | Black |
| Material | Plastic |
| Outer Material | Plastic |
| Product Details | |
| Amperage | 100a |
| Connector Type | Screw |
| Fuse Type | Ato/Atc/Atf |
| Included Components | Great Product |
| Number of Items | 1 |
| Number Of Poles | 6 |
| Type | Fuse Blocks |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 3 inches |
| Length | 5 inches |
| Product Dimensions | 5 x 3 x 3 inches |
| Size | 6 Position |
| Weight | 0.7 pounds |
| Width | 3 inches |
| Technical Specifications | |
| Compatible Fuse Types | ATO / ATC / ATF |
| Max Output Wire Size | #10 AWG |
| Maximum Current (Entire Block) Amps | 100 |
| Maximum Current (Per Circuit) Amps | 30 |
| Voltage Range VDC | 0-36 |
