BEP 1001903 SPDT Toggle Switch - On/Off/On
BEP 1001903 SPDT toggle switch (On/Off/On) — panel-mount with standard black nylon handle, 12V DC operation, rated 25A, three #6-32 screw terminals, 15/32" mounting stem.
$10.99 $10.99
Customize
Available Quantity
3 Product Details
SPDT Toggle Switch - ON/OFF/ON. Single pole, double throw toggle switch turns one of two circuits on. Standard black nylon handle. Nominal voltage is 12V DC. Rated for 25A at 12V DC. Three #6-32 screw terminals. Mounting stem 15/32" fits panels up to 1/8" thick. Replaces Cole Hersee part number 54103. Ideal for marine and industrial electrical control panels requiring a compact, panel-mount on/off/on toggle switch with screw-terminal connections.
- Replaces Cole hersee part number 54103
- Three #6-32 screw terminals. Mounting stem 15/32" fits panels up to 1/8" thick
- Nominal voltage is 12V DC. Rated for 25a at 12V DC
- Standard black nylon handle
- Single pole, double Throw toggle switch turns one of two circuits on
Specifications:
| Materials & Construction | |
| Color | Black |
| Contact Material | Copper Alloy |
| Material | Plastic |
| Product Details | |
| Action | On-Off-on |
| Connector Type | Screw |
| Contact Material | Copper Alloy |
| Included Components | Nylon Toggles |
| Insulation Resistance | 100 Megaohms |
| Material | Plastic |
| Model Name | SPDT Toggle Switch - On/Off/On |
| Mounting Type | Panel Mount |
| Number of Items | 1 |
| Operation Mode | ON-OFF-ON |
| Terminal | Spdt |
| Throw/Pole | Spdt |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 2 inches |
| Item Dimensions Lx Wx H | 2 x 0.7 x 2 inches |
| Item Package Dimensions L x W x H | 5.43 x 2.87 x 1.26 inches |
| Length | 2 inches |
| Product Dimensions | 2 x 0.7 x 2 inches |
| Weight | 0.06 pounds |
| Width | 0.7 inches |
| Technical Specifications | |
| AC Adapter Current | 25 Amps |
| Connector Type | Screw |
| Current Rating | 25 Amps |
| Global Trade Identification Number | 00870216046549 |
| Insulation Resistance | 100 Megaohms |
| Operating Voltage | 12 Volts |
| Voltage | 12 Volts |
