BEP SPST Lighted Toggle Switch - Red LED - 12V - ON/OFF
Customize
Single pole, single throw (SPST) lighted toggle switch designed for panel mount applications. Nominal voltage: 12V DC. Rated for 25A at 12V DC. Features four 1/4" blade terminals, a red LED that illuminates when switched on (clear when off), and a 15/32" mounting hole that fits panels up to 1/8" thick. Contact material is brass with screw-type connector. Mounting type is panel mount; includes nylon toggles. Replaces Cole Hersee part number M-54111-01. Suitable for marine and general electrical applications requiring a robust on/off toggle with illuminated indication. WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (DEHP) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
- Replaces Cole hersee part number m-54111-01
- Four 1/4" blade terminals. 15/32" mounting Hole, fits panels up to 1/8" thick
- Nominal voltage is 12V DC. Rated for 25a at 12V DC
- Switch Illuminates Red when on and is clear when off
- Single pole, single Throw toggle switch turns one circuit on and off
Specifications:
| Materials & Construction | |
| Color | Clear |
| Contact Material | Brass |
| Material | Plastic |
| Outer Material | Plastic |
| Product Details | |
| Action | On-Off |
| Included Components | Nylon Toggles |
| Model Name | SPST Lighted Toggle Switch - Off/On |
| Mounting Type | Panel Mount |
| Mounting Type (duplicate-check) | Panel Mount |
| Throw/Pole | Spst |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 2 inches |
| Length | 2 inches |
| Product Dimensions | 2 x 0.7 x 2 inches |
| Product Weight | 0.06 Pounds |
| Size | One Size |
| Weight | 0.96 ounces |
| Width | 0.7 inches |
| Technical Specifications | |
| AC Adapter Current | 25 Amps |
| Connector Type | Screw |
| Current Rating | 25 Amps |
| Insulation Resistance | 100 Megaohms |
| Operating Voltage | 12 Volts (DC) |
| Operation Mode | ON OFF |
| Speaker Cutout Diameter or Length | 0.47 Inches |
| Terminal | SPST |
| Voltage | 12 Volts |
