BEP 1002010 SPST Sealed Toggle Switch With Wire Leads - Off/On
BEP 1002010 SPST sealed toggle switch (ON/OFF) — IP67-rated panel-mount marine/automotive switch with 10" 14 AWG wire leads. Rated 25A at 12V DC / 15A at 24V DC; chrome plated toggle and 15/32" mounting stem.
$19.99 $19.99
Customize
Available Quantity
14 Product Details
The BEP 1002010 SPST sealed toggle switch is a durable, IP67-engineered on/off toggle designed for marine and automotive applications. Completely sealed with a double O-ring and epoxy back seal, it withstands extreme conditions. Rated 25A at 12V DC and 15A at 24V DC, it features 10" 14 AWG wire lead terminals and a 15/32" mounting stem to fit panels up to 1/8" thick. Chrome plated toggle provides corrosion resistance; replaces Cole Hersee part number 55025. Includes chrome plated toggles and is panel mountable. Ideal for single-circuit on-off applications where a sealed, reliable switch is required.
- Replaces Cole hersee part number 55025
- 10" 14 AWG Wire lead terminals. Mounting stem 15/32" fits panels up to 1/8" thick
- Nominal voltage is 12V/24V DC. Rated for 25a at 12V DC, 15a at 24V DC
- Common applications include Use for any single circuit requiring an on-off style switch
- Single pole, single Throw toggle switch turns one circuit on and off. Engineered to Ip67 specifications utilizing a double O-ring within a bushing at the toggle and a full epoxy seal at the back
Specifications:
| Materials & Construction | |
| Color | Chrome |
| Contact Material | Brass |
| Material | Plastic |
| Product Details | |
| Action | On-Off |
| Included Components | Chrome Plated Toggles |
| Material | Plastic |
| Model Name | SPST Sealed Toggle Switch - Off/On |
| Mounting Type | Panel Mount |
| Operation Mode | ON-OFF |
| Specification Met | IEC 60529 |
| Throw/Pole | Spst |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 2 inches |
| Item Dimensions Lx Wx H | 2 x 1.2 x 2 inches |
| Item Package Dimensions L x W x H | 5.94 x 2.87 x 1.73 inches |
| Length | 2 inches |
| Product Dimensions | 2 x 1.2 x 2 inches |
| Weight | 2.56 ounces |
| Width | 1.2 inches |
| Technical Specifications | |
| AC Adapter Current | 25 Amps |
| Current Rating | 25 Amps |
| Operating Voltage | 24 Volts |
| Terminal | Spst |
| Voltage | 12 Volts |
