Victron Energy Cyrix-Li-Charge 12/24-Volt 120 amp Intelligent Charge Relay

CYRIX-LI-CHARGE 12/24-120A Intelligent Charge Relay Cyrix LI Charge The Cyrix Battery Combiner is a microprocessor-controlled heavy duty relay that automatically connects batteries in parallel when one of them has reached a pre-set voltage (indicating that the battery is being charged) and disconnects when the voltage decreases below float level (indicating that one or more batteries are being discharged). Cyrix Battery Combiners are an excellent replacement for diode isolators. The main feature is that there is virtually no voltage loss so that the output voltage of alternators or battery chargers does not need to be increased. Please contact your dealer for any returns, repairs or support issues related to this product.

• Note: In case of zero discharge current, or a small discharge current, Victron Energy Cyrix will not disengage shortly after the charger has been switched off and/or disconnected, because battery voltage will remain higher than 13.5 V
• If, after the Victron Energy Cyrix has disengaged, the output of the battery charger immediately increases to 13 V or more, Victron Energy Cyrix will reengage, with a 3 seconds delay
• When Victron Energy Cyrix-Li-Charge is engaged (charger connected to battery) it will disengage after 1 hour to check if the charger is still enabled
• In general, a cell over voltage alarm will reset shortly after charging has been stopped. Victron Energy Cyrix will then reconnect the charger after a delay 3 seconds
• Victron Energy Cyrix-Li-Charge will connect a battery charger with 3 seconds delay. Victron Energy Cyrix-Li-Charge will disengage immediately whenever its control input becomes free floating, signalling cell over voltage or cell over temperature
