Victron Skylla - 24/100 TG Charger - 230V
Customize
Skylla - 24/100 TG Charger - 230V. One full rated output and one (1) 4 Amp output. Charge voltage can be precisely adjusted to suit any battery system. The input for the charger is 230V at 50/60Hz. Charge voltage can be measured directly on the battery terminals to compensate for voltage loss due to cable resistance. An external sensor allows measurement of battery temperature and compensation of charge voltage accordingly. Perfect chargers for sealed or unsealed battery systems; prevents overvoltage and excessive gassing in sealed batteries. Suitable for AC and DC supply (AC-DC and DC-DC operation). Every TG Charger has a microprocessor which accurately controls charging in three steps. Can be used as a power supply due to perfectly stabilized output voltage. Manufactured with a battery temperature sensor; when connected, charge voltage will automatically decrease with increasing battery temperature. Voltage sensor compensates for cable resistance so the battery receives correct charge voltage. Technical specifications include Input Voltage: 230V AC (range 185 to 264V AC) and 180 to 400V DC, Battery Capacity: 500 to 1000 Ah, Frequency: 45 to 65 Hz, Battery Connection: M8 studs, 230V AC connection: screw clamp (AWG 6). Item dimensions (per manufacturer): 14.37 x 10.12 x 9.84 inches. Item weight (per manufacturer): 9 kg (approx. 19.84 pounds). In the box: charger, mounting brackets, temperature sensor with 1.5 m wire, instruction manual. Sold as an individual unit. For returns, repairs or support, contact your dealer.
- Victron Skylla - 24/100 TG Charger - 230V
Specifications:
| Materials & Construction | |
| Color | No Color |
| Material | Plastic |
| Product Details | |
| Included Components | Victron Skylla - 24/100 TG Charger - 230V |
| Model Name | Victron Skylla - 24/100 TG Charger - 230V |
| Output Voltage | 24 Volts (DC) |
| Size | One Size |
| Specification Met | CE |
| Warranty Description | Warranty |
| Sizing & Dimensions | |
| Height | 9.84 inches |
| Item Dimensions Lx Wx H | 14.37 x 10.12 x 9.84 inches |
| Item Package Dimensions L x W x H | 3.94 x 3.94 x 3.94 inches |
| Length | 14.37 inches |
| Product Dimensions | 14.37 x 10.12 x 9.84 inches |
| Weight | 19.84 pounds |
| Width | 10.12 inches |
| Technical Specifications | |
| Output Voltage | 24 Volts (DC) |
| Specification Met | CE |
| Warranty Description | Warranty |
